Neodymium Disc - 12 mm x 6.6 mm | N42

Product code: 20030

$2.54for 1 to 9 items
$2.17buy 10 to 99 itemsand save 14%
$1.81buy 100+ itemsand save 29%

Neodymium Disc - 12 mm x 6.6 mm | N42

Product Code 20030
Pull Force* 4.1 kg
Weight 6gm
Style Neodymium Disc
Gauss 4662
Grade N42
Coating Nickel (NiCuNi)
Direction of Magnetisation Axially magnetized
Dimensions Height:6.6mm, Diameter:12mm

Product Description:

This neodymium disc magnet measures 12 mm (D) x 6.6 mm (H). It has a magnetic flux reading of 4662 Gauss and a pull force of 4.1 kg.

Product Information:

These versatile 12 mm x 6.6 mm magnetic discs have a wide variety of purposes. They are valued for their small size, light weight and reliability in all weather conditions. Our customers have used these magnetic discs on camping trips to secure tarpaulins, shade cloths and tent fixtures.

NB: Ranges are indicative for product category, please check individual products for specic values within that range.

The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.

Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.

Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
